SOME NOTES ABOUT POWER CORDS
Long or thin cords can drain the power provided to an electrical device by the generator. When
using such cords, allow for a slightly higher rated wattage requirement by the electrical device.
See Figure 16 for recommended cords based on the power requirement of the electrical device.
Device Requirements Max. Cord Length (ft) by Wire Gauge
Amps Watts (120V) Watts (240 V) #8 wire #10 wire #12 wire #14 wire #16 wire
2.5 300 600 NR 1000 600 375 250
5 600 1200 NR 500 300 200 125
7.5 900 1800 NR 350 200 125 100
10 1200 2400 NR 250 150 100 50
15 1800 3600 NR 150 100 65 NR
20 2400 4800 175 125 75 50 NR
25 3000 6000 150 100 60 NR NR
30 3600 7200 125 65 NR NR NR
40 4800 9600 90 NR NR NR NR
*NR= not recommended
Figure 16- Maximum Extension Cord Lengths by Power Requirement
DC Usage
This Generator is equipped with a cigarette lighter style 12V DC receptacle. The maximum draw
for this DC outlet is 8.3 Amps. The 12V DC receptacle is not intended for use to charge
automotive batteries.
The cigarette lighter style receptacle permits the use of any electrical device designed for use in a
12V DC cigarette style outlet similar to ones found in automobiles. The electrical device has a
power cord with a metal pin on the bottom and two leaf springs on the sides. Some common
automotive type electrical devices are inflators, vacuum cleaners, chargers of various types and
more.
To Use: Simply plug the electrical device power cord into the 12V DC outlet and ensure the power
cord is securely in place. Use the device as instructed. Remove after use by simply pulling the
power cord out of the receptacle. The 12V DC receptacle is protected against overloads by an in-
line fuse located behind the control panel.
22
