EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty
1 70712C-001 Bolt M8X25 1
2 70712B-002 Hex Nut M8, 3.2mm 2
3 70712B-003 Slide Lock Knob 1
4 70712B-004
Pull Rod Locking
Pressure Spring
1
5 70712B-005 Washer 6 1
6 70712B-006 Arm 1
7 70712B-007 Flange 2
8 70712B-008 Pull Rod 2
9 70712B-009 Back Stand 1
10 70712B-010 Bolt 1
11 70712B-011 Line Button 2
12 70712B-012 Bolt M6X10 4
13 70712B-013 Bolt M5X12 4
14 70712B-014 Soft Gasket 2
15 70712B-015 Bevel Lock Knob 1
16 70712B-016 Nut M10 2
17 70712B-017 Washer 10, 2mm 2
18 70712B-018 Washer 10, 4mm 1
19 70712B-019 Right Pointer 1
20 70712B-020 Washer 5 5
21 70712B-021 Spring Washer 5 4
22 70712B-022 Hex Bolt M8X40 1
23 70712B-023 Pole 1
24 70712B-024 Knob 1
25 70712B-025 Wing Bolt M6X14 2
26 70712B-026 Clamp 1
27 70712B-027 Clamp Slice 1
28 70712B-028 Split Washer 5 1
29 70712B-029 Bolt M6X25 2
30 70712B-030
Spring Washer 6
(Fence)
8
31 70712B-031 Wing Bolt M6X38 2
32 70712B-032 Right Slide Fence 1
33 70712B-033 Fence 1
34 70712B-034 Left Slide Fence 1
35 70712C-035 Support Arm 2
36 70712C-036 Base 1
37 70712B-037 Bolt M10X25 1
No. Part No. Description Qty
38 70712B-038 Small Knob M5X33 3
39 70712B-039 Rubber Foot 4
40 70712B-040 Locking Bar 1
41 70712B-041 Seal Ring φ6.3Xφ1.8 1
42 70712B-042
Trigger Spring
(φ8Xφ1.2X52)
2
43 70712B-043 Miter Release Handle 1
44 70712B-044 Miter Lock Knob 1
45 70712B-045 Bolt M6X35 1
46 70712B-046 Table 1
47 70712B-047 Hex Nut M6 1
48 70712B-048 Bolt M5X8 7
49 70712B-049 Spring Card 1
50 70712B-050 Pointer 1
51 70712B-051 Scale Label 1
52 70712B-052 Bolt M10X50 1
53 70712B-053 Set Screw M6X30 1
54 70712B-054 Change Block 1
55 70712B-055 Spring Washer 6 (Base) 1
56 70712B-056 Nut M6 1
57 70712B-057 Table Insert 1
58 70712B-058 Release Knob 1
59 70712B-059 Self Lock Pin Spring 1
60 70712B-060 Round Pin 1
61 70712B-061 Self Lock Pin 1
62 70712B-062 Bearing (φ40Xφ25X35) 3
63 70712B-063 Stand 1
64 70712B-064 Bolt M6X20 1
65 70712B-065 Spring (φ6.5) 1
66 70712B-066 Cross Pin 1
67 70712B-067 Plastic Cover 1
68 70712B-068 Guard Retraction Arm 1
69 70712B-069 Bolt 2
70 70712B-070 Needle Bearing 1
71 70712B-071 Block Circle 1
72 70712B-072 Gear 1
73 70712B-073 Front Cover 1
74 70712B-074 Bearing 1
