KNOW YOUR BAND SAW
A Operating Handle
B ON/OFF Switch
C Blade Guard
D Fence
E Miter Table
F Table Insert
G Miter Table Lock
H Miter Scale
I Bevel Lock Knob
J Slide Bar
K Slide Lock Knob
L Dust Extraction Port
M Guard Retraction Arm
A
B
C
D
E
F
G
H
I
J
K
L
M
UNPACKING
If you find any pieces that are missing or wrong, do not operate the tool until the parts have been replaced. Failure
to do so could result in serious personal injury.
1. Remove all loose parts from the carton and remove the packing materials from around the saw.
2. Using the carrying handle on the back of the saw arm, carefully lift the saw from the carton and place it on a level
work surface.
3. The saw has been shipped with the saw arm locked in the down position. To release the saw arm, push down on
the top of the saw arm, pull on the release knob (FIGURE 2), rotate it 45° and let go, then slowly raise the saw arm.
WARNING - Do not lift the saw using the operating handle or the guards. Use the carrying handle on
the back of the saw arm or by holding the base.
To Next Page
