EXPLODED VIEW & PARTS LIST
23
No. Part No. Description Qty.
1 BA1411-1001 Base 1
2 BA1411-1002 Hex Bolt, M6x55 1
3 BA1411-1003
Flat Washer, 16mm
x 40
2
4 BA1411-1004 Nut, M16 1
5 BA1411-1005 Pin 4
6 BA1411-1006 Lower Wheel Shaft 1
7 BA1411-1007
Ball Bearing,
6204LLU
2
8 BA1411-1008 Key, 5x5x25 2
9 BA1411-1009
Flat Washer, 8mm
x 30
1
10 BA1411-1010
Socket Head
Button Screw,
M8x16
1
11 BA1411-1011 Motor 1
N.P. BA1411-1011.4
Start Capacitor,
200uF 250VAC
1
N.P. BA1411-1011.6 Centrifugal Switch 1
N.P. BA1411-1011.11
Run Capacitor,
20uF 250VAC
1
12 BA1411-1012 Motor Pulley 1
13 BA1411-1013 Set Screw, M6x12 2
14 BA1411-1014 Power Switch 1
15 BA1411-1015
Self-tapping Screw,
M3.5x12
2
16 BA1411-1016
Flat Washer, 4mm
x 8
2
17 BA1411-1017
Phillips Head
Screw, M5x16
2
18 BA1411-1018 Tension Indicator 1
19 BA1411-1019
Toothed Washer,
5mm
2
20 BA1411-1020 Switch Housing 1
21 BA1411-1021 Switch Plate 1
23 BA1411-1023
Phillips Head
Screw, M5x6
2
24 BA1411-1024 Strain Relief 2
No. Part No. Description Qty.
25 BA1411-1025 Power Cord 1
26 BA1411-1026 Motor Cord 1
27 BA1411-1027 Strain Relief 1
28 BA1411-1028 Upper Frame 1
29 BA1411-1029
Upper Guard Knob,
M10x30
1
30 BA1411-1030
Upper Wheel
Bracket
1
31 BA1411-1031 Wing Nut, M8 1
32 BA1411-1032
Tracking Knob,
M8x45
1
33 BA1411-1033ASM
Tension Knob
Assembly
1
34 BA1411-1034 Steel Pin 2
35 BA1411-1035ASM
Upper Wheel Shaft
Hinge Assembly
1
35.1 BA1411-1035.1 Upper Wheel Shaft 1
35.2 BA1411-1035.2
Spring Pin,
4x24mm
1
35.3 BA1411-1035.3
Upper Wheel Shaft
Hinge
1
38 BA1411-1038 Tension Spring 1
39 BA1411-1039 Square Nut, M10 1
40 BA1411-1040 Upper Wheel 1
41 BA1411-1041 Wheel Tire 2
42 BA1411-1042 Nut, M12-1.25 1
43 BA1411-1043
Retaining Ring,
35mm
2
44 BA1411-1044
Ball Bearing,
6202LLU
2
45 BA1411-1045ASM
Lower Wheel
Assembly
1
46 BA1411-1009
Flat Washer, 8mm
x 30
1
47 BA1411-1047
Hex Bolt, M8x20
(LH)
1
48 BA1411-1048
Lower Wheel
Guard
1
49 BA1411-1049 Door Knob, M8 2
BANDSAW
