Wen BA1411 User Manual

EXPLODED VIEW & PARTS LIST
FENCE & RAIL
No. Part No. Description Qty.
ASM-1 BA1411-3012ASM
Fence
Assembly
1
ASM-2 BA1411-3013ASM
Fence Rail
Assembly
1
ASM-3 BA1411-4001 Square Tube 1
1 BA1411-3013.1 Fence Rail Base 1
2 BA1411-3012.2 Fence Base 1
3 BA1411-3012.3 Fence Rod 2
4 BA1411-3012.4 Lock Axle 1
5 BA1411-3012.5 Spring Plate 1
6 BA1411-3012.6 Spacer Plate 1
7 BA1411-3012.7 Fence 1
8 BA1411-3012.8 Bushing 4
9 BA1411-3012.9
Lock Handle,
M8
1
10 BA1411-3012.10
Fence Support
Foot
1
11 BA1411-3012.11 Scale Pointer 1
12 BA1411-3012.12
Socket Head
Cap Screw,
M6x60
4
13 BA1411-3012.13 Lock Cam 1
14 BA1411-4014 Fence Rail Tube 1
No. Part No. Description Qty.
15 BA1411-3012.15 Nut, M8 1
16 BA1411-3012.16
Phillips-head
Screw, M4x6
2
17 BA1411-3013.17 Rail End Cover 2
18 BA1411-3012.18
Fence End
Cover
2
19 BA1411-3012.19
Rail Tube End
Cover
2
20 BA1411-3012.20
Self-tapping
Screw, M3.5-
0.6x12
4
21 BA1411-3013.21 Scale Label 1
22 BA1411-3012.22 Nut, M6 1
23 BA1411-4023
Lock Washer,
6mm
2
24 BA1411-4024
Socket Head
Cap Screw,
M6x16
2
25 BA1411-4025
Hex Bolt,
M6x20
2
26 BA1411-3013.26
Phillips-head
Screw, M4x8
1
27 BA1411-2008
Flat Washer,
6mm x 13
2
28
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.

Wen BA1411 Specifications

General

Brand	Wen
Model	BA1411
Category	Saw
Language	English
