Wen BA4555 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 3975-001
Speed Adjustment
Knob
1
2 3975-002 Circuit Breaker 1
3 3975-003 Motor Housing 1
4 3975-004
Self-tapping Screw,
ST2.9x13
2
5 3975-005 PCB 1
6 3975-006
Pan Head Screw,
M4x8
3
7 3975-007
Pan Head Screw,
M4x8
1
8 3975-008
Toothed Washer,
4mm
1
9 3975-009 Motor Assembly 1
10 3975-010
Socket Head Screw,
M5x10
4
12 3975-012 Strain Relief 1
13 3975-013 Switch 1
14 3975-014
Self-tapping Screw,
ST2.9x9.5
2
15 3975-015 Switch Housing 1
16 3975-016 Indicator Light 1
17 3975-017 Flat Washer, 4mm 2
18 3975-018
Self-tapping Screw,
ST2.9x16
2
19 3975-019 Power Cord 1
20 3975-020 Wiring Harness 1
21 3975-021 Drive Wheel Shaft 1
22 3975-022 Key, 5x5x10mm 1
23 3975-023
Retaining Ring,
15mm
1
24 3975-024 50T Gear 1
25 3975-025 Ball Bearing, 6202ZZ 2
26 3975-026
Retaining Ring,
35mm
2
28 3975-028 Ball Bearing, 607ZZ 2
29 3975-029
Retaining Ring,
11mm
1
No. Part No. Description Qty.
30 3975-030 43T Gear 1
31 3975-031 Key, 4x4x6mm 1
32 3975-032 Pinion Gear 1
34 3975-034
Socket Head Screw,
M8x25
4
35 3975-035 Flat Washer, 8mm 4
36 3975-036 Gearbox 1
37 3975-037 Blade Cover 1
38 3975-038
Pan Head Screw,
M5x8
6
39 3975-039 Flat Washer, 5mm 6
40 3975-040 Left Handle Housing 1
41 3975-041 Button 1
42 3975-042 Spring 1
43 3975-043 Run Trigger Switch 1
44 3975-044 Cord Clamp 5
45 3975-045
Pan Head Screw,
M5x10
5
46 3975-046 Right Handle Housing 1
47 3975-047
Self-tapping Screw,
ST2.9x9.5
3
48 3975-048
Flat Head Screw,
M4x8
4
49 3975-049 Tube 1
50 3975-050 Guide Plate 2
51 3975-051
Socket Head Screw,
M5x10
4
52 3975-052
Socket Head Screw,
M8x25
2
53 3975-053 Lock Washer, 8mm 2
54 3975-054 Set Screw, M8x10 1
55 3975-055 Sliding Block 1
56 3975-056 Blade 1
57 3975-057 Bevel Plate 1
58 3975-058 Ball Bearing, 6201ZZ 2
59 3975-059
Retaining Ring,
32mm
1
17
