EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
60 3975-060 Driven Wheel 1
61 3975-061
Flat Head Screw,
M8x12
1
62 3975-062 Key, 4x4x20mm 1
63 3975-063 Drive Wheel 1
64 3975-064 Flat Washer 1
65 3975-065
Flat Head Screw,
M6x12
1
66 3975-066 Frame 1
67 3975-067 Spring Washer 8
68 3975-068 Blade Tension Knob 1
69 3975-069 Cord Clamp 2
70 3975-070
Pan Head Screw,
M5x8
2
71 3975-071 Set Screw, M6x8 1
72 3975-072 Lock Handle 1
73 3975-073 Flat Washer, 6mm 1
74 3975-074 Nut, M6 4
75 3975-075 Lock Washer, 6mm 4
76 3975-076 Flat Washer, 6mm 4
77 3975-077
Rear Blade Guide
Block
1
78 3975-078 Ball Bearing, 625ZZ 2
79 3975-079 Flat Washer, 5mm 4
80 3975-080 Pin, 5x24mm 1
81 3975-081
Socket Head Screw,
M6x25
1
82 3975-082 Lock Washer, 6mm 1
83 3975-083 Blade Guard 1
84 3975-084 Flat Washer, 6mm 4
85 3975-085 Ball Bearing, 607ZZ 8
86 3975-086 Shaft 4
87 3975-087 Flat Washer, 6mm 2
88 3975-088 Lock Washer, 6mm 2
89 3975-089
Socket Head Screw,
M6x25
2
No. Part No. Description Qty.
90 3975-090
Socket Head Screw,
M5x10
1
91 3975-091 Flat Washer, 5mm 1
92 3975-092 Guard Plate 1
93 3975-093 Pin, 5x35mm 1
94 3975-094
Front Blade Guide
Block
1
95 3975-095 Nut, M6 1
96 3975-096
Socket Head Screw,
M6x25
1
97 3975-097 Nut, M16-1.5 1
98 3975-098 Center Shaft 1
99 3975-099 Torsion Spring 1
100 3975-100 Lock Handle 1
101 3975-101 Flat Washer, 10mm 1
102 3975-102 Swivel Support 1
103 3975-103 Flat Washer, 12mm 1
104 3975-104 Nut, M12 1
105 3975-105
Hex Head Bolt,
M6x25
1
106 3975-106 Nut, M6 1
107 3975-107
Socket Head Screw,
M6x35
1
108 3975-108 Flat Washer, 6mm 1
109 3975-109
Socket Head Screw,
M5x10
2
110 3975-110 Positive Stop Cam 2
111 3975-111 Bushing 1
112 3975-112 Retaining Ring, 8mm 1
113 3975-113 Lock Pin 1
114 3975-114
Pan Head Screw,
M4x8
2
115 3975-115 Angle Scale 1
116 3975-116 Base 1
117 3975-117 Foot 4
118 3975-118
Carriage Bolt,
M10x40
1
18
