Wen CT1274 User Manual

EXPLODED VIEW & PARTS LIST
26
NO. PART NO. DESCRIPTION QTY.
1 CT1274-001 Right Handle 1
2 CT1065-002 Power Cord Clamp 1
3 CT1065-003 Screw ST4x16 18
4 CT1065-006 Trigger Spring 2
5 CT1065-007 Power Switch 1
6 CT1065-008 Plunge Release Button 1
7 CT1065-009
Plunge Release Button
Spring
1
8 CT1274-008 Left Handle 1
9 CT1274-009 Screw ST4x20 3
10 CT1065-012
Power Cord Strain
Relief
1
11 CT1065-011 Power Cord 1
12 CT1065-017 Bearing, 6001ZZ 1
13 CT1274-013 Armature Assembly 1
14 CT1065-019 Bearing, 698ZZ 1
15 CT1065-020 Rotor Bearing Bushing 1
16 CT1274-016 Magnet Ring 1
17 CT1065-023 Motor Dust Shield 1
18 CT1274-018 Screw ST5x68 2
19 CT1274-019 Stator Assembly 1
20 CT1065-028 Motor Housing 1
21 CT1065-029 Carbon Brush Cap 2
22 CT1065-030 Brush Holder 2
23 CT1274-023 Carbon Brush 2
24 CT1274-024 Speed control PCB 1
25 CT1065-015 Trigger 1
26 CT1065-014
Plunge Release Linkage
Arm
1
27 CT1065-024 Flat Washer, 5mm 4
28 CT1065-032
Self-Tapping Screw,
ST4x11
2
29 CT1065-033 Screw, M5x45 4
30 CT1274-030 Magnetic Cover 1
31 CT1274-031 Screw ST3x12 2
32 CT1065-036 Motor Housing Cover 1
33 CT1065-109 Dust Port Adapter 1
34 CT1065-052 Connecting Shaft 1
35 CT1065-043 Screw, M5x8 1
NO. PART NO. DESCRIPTION QTY.
36 CT1274-036 Depth Scale Plate 1
37 CT1065-049 Screw, M4x8 3
38 CT1065-048 Screw, M5x16 2
39 CT1065-047 Spring Washer 5mm 2
40 CT1065-046 Bearing Housing Cover 1
41 CT1065-045 Bearing, 6002zz 1
42 CT1065-044 Bearing Housing 1
43 CT1065-051 Screw M5x8 2
44 CT1065-042 Depth Selector Cover 1
45 CT1065-041
Depth Selector Switch
Spring
1
46 CT1065-056 Locating Pin 1
47 CT1065-040 Depth Selector Switch 1
48 CT1065-059 Roller Pin 1
49 CT1065-039 Depth Selector 1
50 CT1274-050 Gearbox 1
51 CT1274-051 Block 1
52 CT1274-052 Screw M4x6 2
53 CT1065-037 Spindle Lock Sleeve 1
54 CT1065-061 Spindle Lock Spring 1
55 CT1065-063 Spindle Lock 1
56 CT1065-055 Screw, M4x14 6
57 CT1274-057 Outer Blade Cover 1
58 CT1274-058 Arbor Screw 1
59 CT1274-059 Outer Flange 1
60 CT1274-060 Blade 1
61 CT1274-061 Inner Flange 1
62 CT1274-062 Inner Blade Cover 1
63 CT1065-087 Depth Locking Nut 1
64 CT1065-086 Bevel Pointer 1
65 CT1065-085
Self-tapping Screw,
ST3x6
2
66 CT1065-084
Depth Indicator Frame
Base
1
67 CT1065-083 Locating Spring 1
68 CT1065-082
Depth Indicator Rail
Adjustment Button
1
69 CT1065-081 Depth Indicator Frame 1
70 CT1065-080 Knob 1
