27
NOTE: Parts that wear down over the course of normal use (like saw blades, carbon brushes, etc.)
are not covered by the two-year warranty.
EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
71 CT1065-079
Self-tapping Screw,
ST2.5x10
1
72 CT1065-078 Depth Locking Knob 1
73 CT1065-077 Gear Assembly 1
74 CT1065-076 Bearing, 607zz 1
75 CT1065-057
Depth Selector Locating
Pin Spring
1
76 CT1065-058 Steel Ball, Ø3mm 1
77 CT1065-075 Bevel Guide Plate, Rear 1
78 CT1065-060 Bevel Locking Knob 2
79 CT1065-062 Bevel Guide Plate, Front 1
80 CT1065-108 Flat Washer, 6mm 2
81 CT1065-099 Cam Reset Spring 1
82 CT1065-073 Locating Rod Spacer 1
83 CT1065-069
Plunge Return Spring
Rod
1
NO. PART NO. DESCRIPTION QTY.
84 20691-082 Cam Adjustment Knob 2
85 20691-079 O-Ring 2
86 20691-083 Adjustment Cam 2
87 20691-080 Washer 2
88 20691-086 Self-Tapping Screw 3
89 20691-081 Screw M3x6 2
90 20691-084 Washer 2
91 20691-077 Rail Lock Switch 1
92 20691-074 Base 1
93 20691-085 Rail Lock 1
94 20691-088 Screw M6x8 2
95 20691-087 Screw M8x8 2
96 20691-053
Self-tapping Screw
4x34
1
