Wen GN9500X User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 GN9500-001 Pin, Ø8x55 2
2 56500-004 R-clip, Handle 2
3 GN9500-003 Handle 2
4 GN9500-004 Frame Assembly 1
5 56500-007 R-clip, Axle 2
6 GN9500-006 Wheel 2
7 GN9500-007 Washer, Wheel 2
8 GN9500-008 Pin, Ø16x100 2
9 56500-010 Damping Pad 1
10 GN9500X-010 Carbon Tank Bracket 1
11 56500-060 Bolt, M8x16 4
12 GN9500-012 Carbon Tank 1
13 56500-047 Clamp A 2
14 56500-052 Clamp A, Carbon Tank 2
15 GN9500-015 Tube A, Carbon Tank 1
16 GN9500-016 Tube B, Carbon Tank 1
17 GN9500-017 Clamp 1
18 GN9500X-018 Fuel Valve 1
19 GN9500-019 Fuel Tank Assembly 1
20 GN9500-020 Washer 4
21 GN9500-021 Bolt, M6x25 4
22 GN9500-022 Fuel Tank Cap 1
23 GN9500-023 Fuel Gauge Clip 1
24 GN9500X-024 Engine Assembly 1
25 GN9500-025 Plug 1
26 GN9500-303.2 Remote Start Fob 1
27 56500-044 Nut, M6 3
28 GN9500-028 Nut, M5 2
29 GN9500-029 Flat Washer, 5mm 3
30 GN9500-030 Lock Washer, 5mm 3
31 GN9500-031 Bolt, M5x229 2
32 GN9500-032 Bolt, M8x32 2
33 GN9500-033 Washer 2
34 GN9500-034 Gasket, Muffler 1
35 GN9500-035 Muffler Assembly 1
N.P. GN9500-035.1
Spark Arrestor Assem-
bly
1
N.P. GN9500-035.2 Bolt, M5x8 2
GENERATOR
NO. PART NO. DESCRIPTION QTY.
36 GN9500-036 Bolt, M5x14 6
37 GN9500-037 End Cover 1
38 GN9500-038 Bolt, M5x18 3
39 GN9500-039 Voltage Regulator 1
40 GN9500-040
Carbon Brush
Assembly
1
41 56500-022 Bolt, M6x12 7
42 GN9500-042 Bolt, M6x194 4
43 GN9500X-043 Rear Bracket 1
44 GN9500-044 Nut, M10-1.25 4
45 GN9500-045 Damping Bracket Guard 1
46 GN9500-046 Damping Bracket, Rear 2
47 GN9500-047 Nut, M8 4
48 GN9500-048 Bolt, M10-1.25x280 1
49 GN9500-049 Lock Washer, 10mm 1
50 GN9500-050 Flat Washer, 10mm 1
51 GN9500-051 Alternator Assembly 1
52 GN9500-052 Clip 1
53 GN9500-053 Bolt, M5x10 3
54 GN9500-054 Crankcase Cover 1
55 GN9500-055 Damping Bracket, Front 2
56 GN9500-056 Bolt, M10-1.25x40 2
57 GN9500-057 Shipping Bracket 2
58 GN9500-058 Battery Bracket 1
59 GN9500-059 Battery, 9Ah 1
60 GN9500-060 Positive Lead (Red) 1
61 GN9500-061 Negative Lead (Black) 1
62 GN9500-062 Washer 4
63 GN9500X-063 Control Panel Assembly 1
64 GN9500-070 Washer, 6mm 1
65 GN9500-065 Support Base Assembly 1
66 GN9500-066 Support Base 1
67 GN9500-067 Rubber Foot 2
68 GN9500-068 Bolt, M6x18 2
69 GN9500-069 Grounding Wire 1
70 GN9500X-070 Rubber Pad 1
71 GN9500X-071 CO Sensor Module 1
72 GN9500X-072 Nut, M4 2
