Wen MM1011 User Manual

EXPLODED VIEW & PARTS LIST
25
No. Part No. Description Qty.
1 MM1011-001
Self-Tapping Screw,
ST4x16
10
2 MM1011-002 Motor End Cap 1
3 MM1011-003 Screw, M4x12 2
4 MM1011-004 Screw, M5x25 4
5 MM1011-005 Motor Housing 1
6 MM1011-006 Brush Holder 2
7 MM1011-007 Carbon Brush 2
8 MM1011-008 Brush Cap 2
9 MM1011-009 Stator 1
10 MM1011-010 Screw, ST5x65 2
11 MM1011-011 Rotor 1
12 MM1011-012 Fan Shroud 1
13 MM1011-013 Screw, M4x8 14
14 MM1011-014 Cover Plate 1
15 MM1011-015 Blade Housing 1
16 MM1011-016
Lock Pin
Compression Spring
1
17 MM1011-017 Lock Pin 1
18 MM1011-018 Spring Dowel, Ø4x28 1
21 MM1011-021 Washer, 4mm 3
23 MM1011-023
Depth Adjustment
Knob
1
24 MM1011-024 Dust Bag 1
25 MM1011-025
Depth Adjustment
Knob Nut
1
26 MM1011-026
Dust Extraction
Manifold
1
27 MM1011-027 Dust Shield 1
28 MM1011-028
Self-Tapping Screw,
ST4x8
3
29 MM1011-029 Screw, M5x30 2
30 MM1011-030
Self-Tapping Screw,
ST5x16
4
31 MM1011-031 Carrying Handle 1
No. Part No. Description Qty.
32 MM1011-032
Upper & Lower
Handle
1
33 MM1011-033 Power Cord 1
34 MM1011-034
Power Cord Strain
Relief
1
35 MM1011-035 Power Cord Clamp 1
36 MM1011-036 E-Clip 1
37 MM1011-037 Terminal Block 1
38 MM1011-038
Self-tapping Screw,
ST4x25
1
40 MM1011-040 Power Switch 1
41 MM1011-041 Laser Transformer 1
42 MM1011-042 Laser Switch 1
43 MM1011-043 Head Stop Bushing 1
44 MM1011-044 Screw, M6x16 2
45 MM1011-045 Tension Spring Plate 1
46 MM1011-001
Self-Tapping Screw,
ST4x16
2
47 MM1011-047 Torsion Spring 1
48 MM1011-048 O-Ring, Ø10x1.9 1
49 MM1011-049 Frame Locking Pin 1
50 MM1011-050 Knob 2
51 MM1011-051 Knob Spring 1
52 MM1011-052 Nut, M6 4
53 MM1011-053 Rail Bearing Housing 1
54 MM1011-054 Rail Stop Cover, Rear 2
55 MM1011-055
Linear Bearing,
LM25-UU
2
56 MM1011-056
Phillips-Head Screw,
M4x12
5
57 MM1011-057
Torsion Spring
Bushing
1
58 MM1011-058 Hinge Pin 1
59 MM1011-059 Spring Dowel, Ø6x45 2
60 MM1011-060 Arm 1
61 MM1011-061 Rail 2
