EXPLODED VIEW & PARTS LIST
26
No. Part No. Description Qty.
62 MM1011-062 O-Ring, Ø23.6x2.65 2
63 MM1011-063
Rail Stop Cover,
Front
1
64 MM1011-064 Screw, M6x10 2
65 MM1011-065
Wrench Storage
Insert
1
66 MM1011-066 Hex Wrench, 6mm 1
67 MM1011-067 Bevel Indicator 1
68 MM1011-068 O-ring, Ø13x1.9 1
69 MM1011-069 Bevel Stop Pin 1
70 MM1011-070 Bevel Pin Knob 1
71 MM1011-071 Bevel Lock Knob 1
72 MM1011-072 Washer 1
73 MM1011-073 Lock Nut, M10 2
74 MM1011-074 Wavy Washer, 12mm 2
75 MM1011-075 Flat Washer, 10mm 4
76 MM1011-076 Bevel Pivot Pin 1
77 MM1011-077 Screw, M6x35 2
78 MM1011-078 Kerf Board, Rear 1
79 MM1011-079 Table 1
80 MM1011-080 Kerf Board, Front 1
81 MM1011-081
Miter Lock
Connecting Screw
2
82 MM1011-082 Miter Lock Housing 1
83 MM1011-083 Miter Lock Knob 1
84 MM1011-084 E-Clip 1
85 MM1011-085 Miter Lever Spring 1
No. Part No. Description Qty.
86 MM1011-086 Miter Stop Lever 1
87 MM1011-087 Screw 1
88 MM1011-088 Miter Lock Rod 1
89 MM1011-089 Miter Indicator 1
90 MM1011-090 Screw, M10x45 1
91 MM1011-091 Screw, M6x22 1
92 MM1011-092 Ball Bearing, 609Z 2
93 MM1011-093
Intermediate Gear
Shaft
1
94 MM1011-094 Flat Key, 4x4x8 1
95 MM1011-095 Intermediate Gear 1
96 MM1011-096
External Circlip,
12mm
1
97 MM1011-097 Ball Bearing, 608Z 1
98 MM1011-098 Gearbox Housing 1
99 MM1011-099 Screw, M5x20 4
100 MM1011-100 Screw, M4x16 1
101 MM1011-101
External Circlip,
14mm
1
102 MM1011-102 Driving Gear 1
103 MM1011-103 Spindle 1
104 MM1011-104 Flat Key, 5x5x10 1
105 MM1011-105
Internal Circlip,
35mm
1
106 MM1011-106 Ball Bearing, 6003Z 1
107 MM1011-107 Lower Blade Guard 1
108 MM1011-108 Blade Guard Roller 1
