KNOW YOUR MITER SAW
TOOL PURPOSE
Miter saws allow you to easily make cuts at a variety of angles. Refer to the following diagrams to become familiar-
ized with all the parts and controls of your miter saw. The components will be referred to later in the manual for
assembly and operation instructions.
1
2
3
5
6
7
8
9
10
1118
15
16
14
4
13
12
1. Operating Handle
2. Upper Blade Guard
3. Lower Blade Guard
4. Bevel Scale
5. Right Adjustable Fence
6. Base
13. Sliding Bar Lock Knob
14. Workpiece Clamp
15. Left Adjustable Fence
16. Workpiece Support Bar
17. Support Bar Lock Knob
18. Miter Table
7. Mounting Hole
8. Table Insert
9. Miter Lock Knob
10. Miter Angle Adjustment Lever
11. Miter Scale
12. Sliding Bar
10
17
