CONNECTING RISER SECTIONS (CONTINUED)
6. Use the riser spacer tool to align the
edges of the pie-shaped units vertically.
Make sure the corners of the decks are
aligned.
7. Connect all matching height units together
using the unit-to-unit clamps.
8. Connect different height pie-shaped units
together using metal spacer assemblies.
9. Assemble the next section ( pie-shaped
units) to the right of the completed
sections, again repeating steps 6 - 8 and
connecting same-height sections with the
unit-to-unit clamps.
9. Continue until all sections are installed.
!
WARNING
Always install all leg
spacers, and secure
each section with
unit-to-unit clamps,
before beginning a
new section.
