INSTALLING GUARD RAILS
To attach each guard rail assembly to the platform
system:
1. Unscrew the handle at the bottom of each
upright, just until pulling the handle outward
allows the lower shoe to drop. Don’t unscrew
all the way.
2. Set the guard rail on the platform, with the
lower shoe on each upright positioned below
the deck surface. Center the rail side-to-side
on the platform section.
3. Lift the lower shoe on each upright until the
handle drops.
4. Slide the Rail against the platform deckand
turn the handle until the lower shoe is tight
against the platform deck.
