SETTING UP INDIVIDUAL PLATFORM UNITS
1. Bring the platform units to the set up area.
2. Open all legs on the platform units.
3. Straighten the hinged brace on each leg.
Pull the brace until the lock engages.
4. Dual-Height Models.
Adjust the legs to the desired height:
a. Pull the lower leg body out until the
locking tabs are visible (A).
b. Rotate the lower leg a quarter-turn (B).
c. Engage the locking tabs and lock them
into the upper leg body (C).
5. Depress the foot pedal with your left foot,
and gently push the unit down to the floor.
To keep the platform from rolling, maintain
firm pressure on the pedal.
Note: Units can be moved into their final
position by releasing the pedal just before
the legs rest on the floor. Once the unit is in
the desired location, depress the pedal
again and gently push the unit down until it
sets firmly in place. Lock the caster brakes.
Note: Stagehand platforms have locking
gas springs that are actuated only when the
pedal is fully depressed. If the pedal is
releasedl while raising or lowering the deck,
the gas springs lock and the deck won’t
move further up or down.
6. Repeat steps 2 - 5 for the remaining
platform units.
