OPERATOR’S)MANUAL))
Page!6!)
WerkMaster machines come with a variety of different plug configurations. The
following table lists the plug used on the COBRA, RAZOR and the PYTHON.
!
MODEL COBRA PYTHON RAZOR
Voltage
250V
250V
250V
Breaker Size
30 A
30 A
30 A
Phase Configuration
3 Phase
3 Phase
3 Phase
Cord End
4 pole 3 wire twist lock
4 pole 3 wire twist lock
4 pole 3 wire twist lock
!
WerkMaster machines come in a variety of voltage and phase configurations.
The COBRA, RAZOR and PYTHON are typically configured to operate on 208-
230V three-phase power. They are capable of operating on single-phase 208-
230V power with the use of a single-phase to 3-phase adapter cord (included),
as well as 110V using a Quick 220 and a 20 Amp adapter cord.
Pigtails are plug ends with unfinished bare wire on one end for hooking up to
panels. Pigtails are used when connectivity is unknown, when connecting to the
power grid of an unfinished building that has no power receptacles, or when
operating certain generators. Many pigtails are available or can be made up by
an electrician.
ONLY certified electricians should make and/or install a pigtail in to a
panel.
Draws power from either a stove/range or a dryer outlet and breaks it out into 2 x
20 Amp circuits that can be used to power both a WerkMaster machine and
auxiliary equipment such as a vacuum of the 110V Quad Box (sold separately).
When using the machines in a residential environment, source power may be
hard to find. Plug two 110V cords from the Quick 220 into the 110V wall outlet on
two (2) separate circuits on opposite sides of the panel. Plug the WerkMaster
machine into the 20 AMP TO 30 AMP adapter cord and the cord into the Quick
220 Adapter.
NOTE: For both the Breakout Box and the Quick 220Adapter a 20 Amp to 30
Amp single-phase to three-phase adapter with a 10/3 cord (sold separately) OR
a 20 Amp to 30Amp to three-phase adapter on a 10/4 cord (sold separately) is
required.
The following table lists the minimum requirements for power cords.
!
General Connections
Adapter Cords
Pigtails
Breakout Box
Quick 220 Adapter
Power Cord
Minimum Requirements
MODEL
DISTANCE
MINIMUM REQUIREMENT
COBRA
Up to 300 ft
Single-phase minimum gauge of 10/3
Three-phase minimum gauge of 10/4
PYTHON
Up to 300 ft
Single-phase minimum gauge of 10/3
Three-phase minimum gauge of 10/4
RAZOR
Up to 300 ft
Single-phase minimum gauge of 10/3
Three-phase minimum gauge of 10/4
! ! ! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! ))DANGER)
