ITEM
QTY
PART NUMBER
DESCRIPTION COLOSSOS XT
!
!
!
!
1
1
530-0007-01
Motor
2
1
500-0079-00
Bushing
3
1
540-0078-00
VFD
4
5
590-0144-00
Lock Washer
5
12
590-0142-00
Lock Washer
6
8
590-0124-00
Fastener
7
1
120-0003-02
Motor Shroud Assembly
8
10
590-0114-00
Fastener
9
8
590-0159-00
Fastener
10
13
590-0140-00
Fastener
11
2
590-0166-00
Fastener
12
4
590-0050-00
Lock Washer
13
4
590-0217-00
Fastener
14
8
100-0176-00
Drive Spacer
15
2
500-0197-00
Bearing
16
1
500-0247-00
Idler Sprocket
17
1
100-0609-02
Offset Idler Shaft
18
8
590-0120-00
Fastener
19
1
500-0267-00
Sprocket
20
7
500-0266-00
Sprocket
21
17
500-0013-00
Bearing
22
1
540-0069-00
Strain Relief
23
1
540-0073-00
Strain Relief
24
1
100-0120-01
Drive, Idler Shaft Spacer
25
1
500-0248-00
Bushing
26
1
550-0007-00
Key Stock
27
1
100-0573-01
Drive Train, Lower Plate
28
1
100-0572-01
Drive Train, Upper Plate
29
1
110-0072-01
Cover Assembly
30
1
100-0115-01
Belt Check Plate Cover
31
1
100-0137-03
Motor Mounting Plate
32
1
100-0216-03
Lifting Lug, Motor Mounting Plate
33
12
590-0128-00
Fastener
34
8
540-0152-00
Vibration Dampener
35
8
590-0133-00
Fastener
36
24
008-0154-00
Bumper
37
16
008-0143-03
Shear Pins
38
16
008-0189-00
Shear Pin Grommet
39
2
110-0073-00
Vacuum Tube Assembly
40
2
540-0156-00
Strain Relief
41
1
540-0002-00
Mating Receptacle
42
1
540-0072-00
Strain Relief
43
2
590-0047-00
Reducing Washer
44
1
540-0268-00
Strain Relief
45
1
540-0319-00
Cable
46
2
540-0268-00
Cable Retainer
47
1
540-0066-00
Plug
48
1
008-0319-00
Weather Strip
49
1
540-0266-00
Conduit
50
8
590-0115-00
Fastener
51
1
550-0009-00
Key Stock
52
16
590-0055-00
Fastener
53
1
008-0309-01
Dust Skirt
54
1
008-0320-00
Velcro Loop
55
1
590-0244-00
Fastener
56
1
100-0611-00
Idler Wrench
57
1
590-0193-00
Fastener
58
1
100-0585-01
Bearing Plate
59
3
590-0169-00
Fastener
60
1
500-0252-00
Sprocket
61
1
520-0042-00
Belt
!
!
