OPERATOR’S!MANUAL!!
+,-.!XT!!
!
62
1
500-0253-00
Sprocket COLOSSOS XT
63
8
590-0258-00
Fastener
64
8
008-0360-00
Plate, Plug ‘N Go
65
48
580-0033-00
Magnet
66
48
590-0182-00
Fastener
67
16
008-0208-00
Bumper
68
8
008-0359-02
Pad Driver
69
1
580-0070-00
Quick Release Pin
70
2
580-0095-00
Wheel
71
2
500-0198-00
Bearing
72
2
590-0132-00
Fastener
73
4
590-0135-00
Fastener
74
2
590-0230-00
Flat Washer
75
1
590-0237-00
Fastener
76
2
590-0000-00
Flat Washer
77
4
590-0232-00
Washer
78
1
130-0071-02
Handle, Main Frame
79
2
130-0073-02
Handle, Extender Assembly
80
2
100-0555-01
Hitch
81
2
580-0098-00
Retaining Ring
82
4
540-0179-00
Threaded Bumper
83
2
590-0147-00
Flat Washer
84
2
540-0240-00
Bumper
85
2
130-0076-02
Handle Assembly
86
1
100-0226-02
Handle, Wheel Axle
87
1
100-0558-01
Protection Plate
88
1
540-0116-00
Potentiometer
89
1
540-0117-00
Potentiometer Knob
90
1
100-0215-01
Handle Cover Plate
91
1
540-0006-00
Stop Button, Red
92
1
540-0005-00
Start Button, Green
93
2
540-0003-00
Cord
94
2
580-0122-00
Handle Grip
95
1
540-0144-00
Strain Relief
96
2
590-0192-00
Fastener
97
1
580-0190-00
Quick Release Pin
98
1
520-0041-00
Belt
99
1
580-0104-00
Chain
100
8
008-0368-00
Plate Assembly
101
8
008-0367-00
Pad Driver Plate Assembly
102
8
008-0310-01
Compression Foam
103
1
540-0308-00
Grounding Wire Assembly
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
