NOTE:
There
should
be
no
continuity
found
between
the
field
coils
and
the
generator
body.
7.
Replacement
of
Field
Coil(s)
Field
coils
are
connected
in
series
and
the
reisitance
value
given
above
in
this
text
is
the
total
of
the
four
field
coils.
To
determine
the
resistance
value
of
one,
divide
by
four.
Each
field
coil
has
a
mounting
position
on
the
generator
housing
and
cannot
be
interchanged
with
another
field
coil.
When
installing
a
replacement
field
coil
(s),
the
installer
must
insure
that
the
coil
is
correct
for
the
mounting
position
in
the
housing
and
will
have
the
correct
polarity
when
excited
with
9 -
12
volts
DC.
The
field
coil
shoes
that
hold
the
coil
securely
to
the
generator
housing
are
held
in
palce
by
bolts
that
must
be
properly
tightened
when
the
coil
and
shoe
are
installed
to
the
generator
housing.
When
connecting
the
coils
in
series
insure
the
butt
connections
are
good
and
secure
and
positioned
away
from
rotating
parts.
To
insure
the
field
coils
have
been
posi
tioned
proper
ly
in
the
generator
housing
and
will
have
the
correct
polarity,
the
following
test
must
be
made
before
reassembly
of
the
generator.
(1)
Connect
a 9 -
12
volt
DC
battery
to
the
leads
off
the
coils
that
would
normally
be
connected
to
the
(+)
and
(-)
connectors
of
the
bridge
rectifier.
These
leads
are
unmarked
and
the
polari
ty
in
their
connection
to
the
DC
battery
is
not
important.
NOTE: When
remov
ing
the
leads
from
the
battery
and
recon-
necting
them
to
the
bridge
rec-
tifier,
you
should
maintain
the
same
polar
i
ty
as
used
in
this
test,
plus
lead
to
(+)
on
rec-
tifier
and
negative
to
unmarked
(-)
connection
on
rectifier.
(2)
Wi
th
a 3
inch
iron
bolt
or
its
equivalent,
place
this
bolt
bet-
ween
each
adjoining
field
coil
shoe.
It
should
be
held
in
place
by
the
magnetic
attraction
set
up
between
the
coil/shoes
by
9-12
Volt Battery
DC
the
9 -
12
volts
excitation
of
the
field
coils.
Should
this
fail
to
happen
between
any
of
the
four
adjoining
coils/shoes,
then
an
incorrect
coil
is
installed
and
must
be
removed
and
the
correct
one
installed~
otherwise
the
generator
when
assembled
will
not
produce
proper
voltage.
