curved
plates,
dissipates
the
heat
and
prevents
fire
from
extending
through
the
arrestor.
5.
COOLING
SYSTEM
a.
All
engines
are
equipped
with
a
positive
displacement
type
water
pump.
Six
and
eight
cylinder
en-
gine
pumps
are
rubber
impeller
type.
Two
and
four
cylinder
engines
have
bronze
gear
pumps. The
oppo-
site
type
in
each
case
can
be
ob-
tained
on
special
order.
b.
In
the
Twin,
Atomic,
Utility
and
Super-Four,
the
water
flow
is
from
pump
to
block,
to
head,
to
manifold,
then
overboard.
In
the
case
of
the
Unimite,
the
flow
is
from
pump
to
manifold,
to
block,
to
head,
then
overboard.
All
six
cylinder
engines
have
the
same
flow
which
is:
pump
to
oil
cooler,
to
manifold
for
one com-
plete
pass,
then
into
block
through
four
to
six
holes
(depending
on
engine
size),
then
to
head,
to
heat
riser
on
intake
manifold,
and
then
overboarde
c.
See
special
diagram
of
rather
complicated
water
flow
in
special
manual
furnished
with
each
v-8
engineo
d.
Where
either
manual
or
automatic
temperature
control
is
used,
vary-
ing
amounts
of
discharge
water
will
be
recirculated.
See
Fig.
11.
6.
REVERSING
GEARS
Four
types
of
reversing
gear
sys-
tems
are
used
on
UNIVERSAL
engines
covered
by
these
instructions.
Three
of
these
are
mechanically
operated,
and
the
fourth
is
a
hy-
draulic
system.
a.
Joes
Model
Reversing
Gear
(1)
The
Joes
is
currently
model
reversing
being
used
on
gear
the
-41-
Super-Four
series
engines
only.
(2)
The
forward
.d.r
ive
on
this
unit
is
a
double
friction
clut9h.
On
the
propeller
end
are
a
series
of
fric-
tion
discs
of
steel
and
bronze
which
are
mortised
into
the
engine
and
propeller
drives
and
casing.
On
the
engine
end,
a
split
cone
clamps
the
engine
shaft
and
frictionally
locks
the
gears
to
it.
(3)
When
the
reversing
gear
lever
is
moved
forward
the
toggles
force
home
the
plungers,
clamping
all
friction
surfaces
together.
All
moving
parts
are
then
locked
and
the
whole
unit
functions
as
a
solid
coupling
be-
tween
the
motor
and
propeller
shafts.
(4)
Reverse
drive
is
obtained
by
throwing
the
lever
back.
This
re-
leases
the
forward
drive
and
throws
on
the
brake
band
by
means
of
a
camG
This
cam
passes
through
a
slot
in
the
camshaft
that
operates
between
the
cam
roll
and
cam
shoe.
This
clamps
the
brake
band
and
prevents
the
outside
case
from
revolving.
When
the
casing
is
thus
held
from
revolving,
the
gearing
drives
the
propeller
in
the
reverse
direction
at
80 -
88%
of
the
motor
speed~
(5)
To
place
in
neutral,
the
leve=
is
placed
midway
bety/een
forward
and
reverse,
which
releases
both
the
reverse
and
forward
drives
and
permits
the
gearing
to
run
idle~
b.
Paragon
Model
Reversing
Gears
(1)
Paragon
reversing
gears
are
used
on
all
current
production
en-
gines
except
the
Super-Four
and
those
models
which
are
equipped
with
hydraulically
operated
reversing
gears
or
Sta-Nu-Tral
manual
gears.
(2)
Power from
the
engine
is
trans-
mitted
through
the
engine
sleeve
gear
and
the
reverse
idler
pinions
to
the
forward
clutch
or
to
the
re-
verse
drive
gear.
(3)
The
forward
clutch
consists
of
