3.3. Hardware Overview
321
5 4
No. Description No. Description
1 LED indicators 2 SFP transceivers
3 Power connection 4 I/O connection
5 Ethernet connection TX
Figure 3. Location of interface ports and LED indicators
12 Lynx L110-F2G & L210-F2G
