Each SFP slot can hold one SFP transceiver. See "Transceiver User Guide 6100-0000" for
transceiver handling instructions, which also can be downloaded from the product support
pages at www.westermo.com/support/product-support.
In the event of contamination, the optical connectors in the SFP transceivers should only
be cleaned by the use of forced nitrogen and some kind of cleaning stick. Recommended
cleaning fluids are methyl-, ethyl-, isopropyl- or isobutyl alcohol, hexane or naphtha.
3.7. Supported Transceivers
Firmware prior to 4.4.0 accepts Westermo branded transceivers only. From 4.5.0 other
transceivers are accepted with a notice and the product will no longer be UL approved.
Temperature specifications are also depending on the used transceivers.
CAUTION - HANDLING OF SFP TRANSCEIVERS
SFP transceivers are supplied with plugs to avoid contamination inside the
optical port. They are very sensitive to dust and dirt. If the fibre is
disconnected from the product, the protective plugs on the transmitter/
receiver must be connected. The protective plugs must be kept on during
transportation. The fibre optics cables must be handled the same way.
3.8. Deviations
With copper transceiver 1100-0148, the specified operating temperature of the product is
0 to 50ºC. FRNT reconfiguration times can not be guaranteed with copper transceivers.
Lynx L110-F2G & L210-F2G 17
