5. Specifications
5.1. Interface Specifications
DC, Power port
Lx10-F2G: Lx10-F2G-12VDC:
Rated voltage 24 - 48 VDC 12 - 48 VDC
Operating voltage 19 - 60 VDC 9.8 - 60 VDC
Rated current 240 mA at 24 VDC
120 mA at 48 VDC
420 mA at 12 VDC
220 mA at 24 VDC
115 mA at 48 V
Rated frequency DC
Inrush current, I²t 22.7 mA
2
s at 48 VDC 53 mA
2
s at 12 VDC
20 mA
2
s at 48 VDC
Startup current
a
2 x rated current
Polarity Reverse polarity protected
Redundant power input Yes
Isolation All other ports
Connector Detachable screw terminal
Conductor cross section 0.2-2.5 mm² (AWG 24-12)
Stripping length cable 7 mm
Tightening torque, terminal
screw
0.5 - 0.6 Nm
Terminal torque, screw flange 0.3 Nm
Shielded cable Not required
a
Recommended external supply current capability for proper startup
Lynx L110-F2G & L210-F2G 23
