5.2. Type Tests and Environmental Conditions
Environmental
phenomena
Basic standard
Description Test levels
ESD EN 61000-4-2 Enclosure Contact: ±6 kV
Air: ±8 kV
Fast transients EN 61000-4-4 Power port ± 2 kV
Signal ports
Earth port ± 1 kV
Surge EN 61000-4-5 Power port L-E: ± 0.5 kV, 12 Ω, 9 µF
L-L: ± 0.5 kV, 2 Ω, 18 µF
L-E: ± 2 kV, 42 Ω, 0.5 µF
L-L: ± 2 kV, 42 Ω, 0,5 µF
L-E: ± 2 kV, 12 Ω, 9 µF
L-L: ± 1 kV, 12 Ω, 9 µF
Signal ports L-E: ± 1 kV, 2 Ω
L-L: ± 2 kV, 42 Ω, 0.5 µF
Power frequency
magnetic field
EN 61000-4-8 Enclosure 300 A/m; 0, 16.7, 50 Hz
Pulsed magnetic field EN 61000-4-9 Enclosure 300 A/m
Radiated RF immunity EN 61000-4-3 Enclosure 10 V/m at (80 - 800) MHz)
20 V/m at (800 - 1000) MHz
10 V/m at (1.4 - 2.1) GHz
5 V/m at (2.1 - 2.5) GHz
1 V/m at (2.5 - 2.7) GHz
1 kHz sine, 80% AM
Conducted RF
immunity
EN 61000-4-6 Power port 10 V, 80% AM, 1 kHz; (0.15-80)
MHz
Signal ports
Earth port
Radiated RF emission CISPR 16-2-3
ANSI C63,4
(FCC Part 15)
Enclosure Class A
Conducted RF emission CISPR 16-2-1
ANSI C63,4
(FCC Part 15b)
Power port Class B
Signal ports
Dielectric strength EN 60950-1 Power port to all
other ports
1.5 kVrms, 50 Hz, 1 min
Signal ports to all
other ports
Table 11. EMC and electrical conditions
26 Lynx L110-F2G & L210-F2G

Westermo Lynx SERIES Specifications

General

Model	Lynx SERIES
Management	Web interface, CLI, SNMP
Operating Temperature	-40°C to +70°C
Mounting	DIN-rail
Dimensions	Varies depending on model
Weight	Varies depending on model
Standards	IEEE 802.3
Category	Industrial Ethernet Switch
