Westermo Lynx SERIES User Manual

I/O connection, Digital input
Maximum voltage/load
current
60 VDC/2mA
Isolation To all other ports
Connector Detachable screw terminal
Conductor cross section 0.14 - 1.5 mm² (AWG 28-16)
Stripping length cable 7 mm
Tightening torque, terminal
screw
0.22 - 0.25 Nm
Terminal torque, screw flange 0.3 Nm
Voltage levels Logic one: >12 VDC
Logic zero: <1 VDC
Console port
Electrical specification TTL-level
Data rate 115.2 kbit/s
Circuit type SELV
Data format 8 data bits, no parity, 1 stop bit, no flow control
Connection 2.5 mm jack, use only Westermo cable 1211-2027
Lynx L110-F2G & L210-F2G 25

Westermo Lynx SERIES Specifications

General

Model	Lynx SERIES
Management	Web interface, CLI, SNMP
Operating Temperature	-40°C to +70°C
Mounting	DIN-rail
Dimensions	Varies depending on model
Weight	Varies depending on model
Standards	IEEE 802.3
Category	Industrial Ethernet Switch
