Westermo Lynx SERIES User Manual

Ethernet TX
Electrical specification IEEE std 802.3
Data rate 10 Mbit/s, 100 Mbit/s, manual or auto
Duplex Full or half, manual or auto
Circuit type TNV-1
Transmission range Up to 150 m with CAT5e cable or better
Isolation All other ports
Connector RJ-45, auto MDI/MDI-X
Cabling Shielded CAT5e or better is recommended
Conductive chassis Yes
Number of ports 8
Ethernet SFP pluggable connections (FX or TX)
Electrical specification IEEE std 802.3
Data rate 100 Mbit/s, 1000 Mbit/s, transceivers supported
Duplex Full or Auto, depending on transceiver
Transmission range Depending on transceiver
Connection SFP slot holding fibre transceiver or copper transceiver
Number of ports 1 or 2
I/O connection, Relay output
Maximum voltage/current 60 VDC/80 mA
Connect resistance Maximum 30 Ω
Isolation To all other ports
Connector Detachable screw terminal
Conductor cross section 0.14 - 1.5 mm² (AWG 28-16)
Stripping length cable 7 mm
Tightening torque, terminal
screw
0.22 - 0.25 Nm
Terminal torque, screw flange 0.3 Nm
24 Lynx L110-F2G & L210-F2G
