Problem solving
FAULT CAUSE SOLUTION
Machine does not work
Mains plug not plugged in Establish connection
Fuse or PROTECTIVE MOTOR SWITCH (Reset) tripped Check fuse or PROTECTIVE MOTOR SWITCH (Reset)
Power interrupted Check connection
Cleaning action inadequate
Brush/pad badly worn Replace brush/pad
Dosing too low Turn up dosing
No suction or suction inadequate
Suction nozzle clogged Remove clogging
Suction hose not connected Connect suction hose
Tank lid not closed or seal defective Close tank lid correctly or replace seal
Filter screen for air suction channel in float unit clogged Remove float unit and clean integrated screen with
water
Sealing lid at outlet hose not correctly screwed on or
seal faulty
Check seal, screw on lid firmly, replace if necessary
Turbine at OFF position Set turbine to ON Pposition
Streak formation
Suction lips contaminated or worn Clean or replace suction lips
Incorrect angle setting for suction nozzle Set angle of suction nozzle correctly
No supply of cleaning agent or water, or supply
inadequate
Tubes clogged Rinse fresh water tank and tube system with clean
water
Fresh water screen clogged Clean fresh water screen
Valve at OFF position Set valve to ON position
No fresh water in tank Fill with fresh water
Batteries not charged or charge is too low
Duration of battery charging too short Observe the required charging duration
End of battery service life reached Change batteries (observe safety instructions)
Technical specifications
Scrubo 43 E Scrubo 43 B/BI
Nominal voltage:
V 230V-240V 24V DC
Theoretical power:
m2/h 1720 1720
Operating width:
mm 430 430
Width of suction nozzle, folded:
mm 790 790
Fresh water tank:
l 33 30
Dirty water tank:
l 40 40
Brush motor
W 1000 600
Suction turbine
W 1100 370
Valve
W 15 15
Overall nominal rating:
W 2115 985
Battery capacity
Ah - 70
Duration of battery charge
h - max. 2.5
Weight without battery, without water:
kg 56 57
Scrubo 43 E Scrubo 43 B/BI
Weight with battery 70 Ah:
kg - 124
Weight: battery+water:
kg 89 154
Max. dimensions (LxBxH):
mm 1100x510x1100 1150x510x1100
Underclearance
mm 650 770
Suction turbine
mbar (l/s) 165 (42) 110 (31.7)
Brush pressure:
N/cm2 0.3 0.26
Brush pressure:
kg 41 36
Brush rpm:
1/min. 150 140
Cable length
m 20 -
Noise level (DIN)
dB (A) 71 65
Max. permissible incline
% 2 2
Anti-splash protection :
IP.. IP X4 IP X4
Certification mark:
CE
✔ ✔
Scrubbing brush
Tynex (very hard)
