Glasstilt Rev. 2.0 (202202)
Technical specifications
55
* option
** Factory setting. The wash time is adjustable.
*** Applies under ideal conditions. The water consumption depends on local
conditions. Fine adjustments can be made during installation.
**** in accordance with EN 60 335-2-58, §ZAA.2.8 with instruments that satisfy
class 1.
Measurements of the sound pressure level on site are performed in three places
20 cm from the edges of the front at a height of 1.55 m using a microphone.
When measuring sound power level, create an imaginary measurement area
consisting of five sides at a distance of 1 m from all edges of the machine.
* Other voltages on request
** 2-metre-long cable included
CAPACITY AND
OPERATING DATA
WD-6 WD-7 WD-6 DUPLUS WD-7 DUPLUS
Total washing time “Beer glasses” (P1)
(min.) **
1.2 1.2 1.4 1.4
Total washing time “Standard glasses” (P2)
(min.) **
1.2 1.2 1.4 1.4
Total washing time “Wine glasses” (P3)
(min.) **
2.2 2.2 2.4 2.4
Max. capacity, baskets/hour (no.) 50 / 36 * 50 / 36 * 50 / 36 * 50 / 36 *
Water consumption rinsing/programme (l)
***
2.5–4 2.5–4 1–1.5 1–1.5
Sound pressure level, L
PA
(dBA)
Normal load / Heavily soiled loads ****
60 62 / 60 60 62 / 60
Sound power level L
WA
(dBA) **** 72 74 / 72 72 74 / 72
CONNECTION, MACHINE WD-6 WD-7 WD-6 DUPLUS WD-7 DUPLUS
Total connected load (kW) 12.9 13.1 9.9 10.1
Main fuse 400 V 3N~(A) * 25 25 16 16
Max. connection area 400V 3N~
(L1-L3, N, PE) Cu (mm²) **
2.5 2.5 2.5 2.5
WATER, DRAIN AND VENTILATION CONNECTIONS WD-6
WD-7
WD-6 DUPLUS
WD-7 DUPLUS
Water quality, hardness (°dH) 2–7 2–7
Water connection 5-65°C (exterior thread) R½" R½"
Drain connection, PP pipe (ø mm) 50 50
Water capacity, pressure (kPa) 20 20
Water capacity, flow (litres/min.) 5 5
Floor drain, capacity (litres/sec.) 3 3
Heat load room, latent / sensitive / total (kW) 0.6 / 1.7 / 2.3 0.5 / 1.2 / 1.7
