Glasstilt Rev. 2.0 (202202)
Technical specifications
54
5. Technical specifications
The manufacturer reserves the right to make changes to the technical data.
* option
TECHNICAL DATA WD-6 WD-7 WD-6 DUPLUS WD-7 DUPLUS
Washing pump (kW) 0.9 1.1 0.9 1.1
Pump motor, recirculating rinse (kW) --- --- 0.58 0.58
Pump motor, final rinse (kW) --- --- 0.58 0.58
Return pump, recirculating tank (kW) --- --- 0.045 0.045
Booster heater (kW) 12 12 9 9
Tank heater (kW) 1.8 1.8 5.4 5.4
Booster pump (kW) 0.58 0.58 0.58 0.58
Drain pump (kW) * 0.04 0.04 0.04 0.04
Heat recovery fan (kW) * 0.13 0.13 0.13 0.13
Heat recovery fan, flow (m³/hour) * 250 250 250 250
Heat recovery, cooling surface (m²) * 12 12 12 12
Tank volume, chemical wash tank (litres) 50 50 45 45
Tank volume, recirculating rinse (litres) --- --- 5.5 5.5
Weight, machine in operation (kg) 160 / 185 * 170 / 195 * 185 195
Enclosure protection class (IP) 45 45 45 45
