WHEATON UniSpense
®
PRO Peristaltic Pump
WHEATON | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | www.wheatonsci.com| P/N 50099073 Rev. 2/2/10 Lit. No.8734
22
FIGURE B – Lower Housing Assembly
ITEM USE QTY. WHEATON NO. DESCRIPTION
1
1 50099007 ALUMINUM BASE CABINET
2
1 WI056857 PCBA, REMOTE I/O
3
1 WI056858 MOTOR, STEPPER
4
1 WI056859 UNIVERSAL POWER SUPPLY, 48V, 3.2A
5
1 50099058 POWER SUPPLY STABILIZER BRACKET
6
1 WI056856 PCBA, CPU, OMNISPENSE ELITE
7
1 WI056863 POWER INLET
8
1 WI056860 POWER SWITCH
9
4 50099059 ADHESIVE RUBBER FEET
10
1 50099060 PUMP HEAD DRIVE ADAPTER
11
2 50029991 SCW, SET, 8-32 X 3/16" LG
12
4 50099061 SCW, SET, 10-32 X 1/2" LG
13
4 50099062 SCW, M4X8, SS, PPHM
14
1 I052239 SCW, 6-32 X 1/4 PPHM
15
1 50029919 NUT,HEX,6-32
16
1 I052273 WASHER,STAR,#6,INT TOOTH
17
1 50099063 STF, 6-32 X 1/4, ALUMINUM
18
2 WI056864 FUSE, 5X20MM, 2.0AT, 250V (120V)
18
2 WI056862 FUSE, 5X20MM, 1.0AT, 250V
FIGURES C THRU E – Upper Housing Assembly, Main Assembly and Wiring Diagram
ITEM USE QTY. WHEATON NO. DESCRIPTION
19
1 50099005 PLASTIC UPPER HOUSING, CABINET
20
1 WI056861 LCD, DISPLAY, 240 X 128, BACKLIT
21
1 50099072 CONTROL KEYPAD OVERLAY, UNISPENSE PRO
22
4 50099068 SCW, PLASTITE 48, TRILOBE, #4 X 0.250
23
1 50099006 SCREEN, VENT, PLASTIC
24
4 50099070
SCW,PLASTITE, 48 TRILOBE, #8 X .750, PPH,
STEEL/ ZINC
25
1 50099065 ASS'Y, WIRE HNS, OMNI ELITE
26
1 50028826 LABEL, LINE VOLTAGE
27
1 50027794 LABEL, UL APPROVED, SERIAL #
28
1 50028394 LABEL, MET NRTL LISTED, OMNI / FLOW
29
1 50028414 LABEL, CAUTION
30
1 50028416 LABEL,CE (MARK) (230V)
UniSpense
®
PRO is a trademark of WHEATON Industries, Inc.
Stylized “W” is a registered trademark of WHEATON Industries, Inc.
Specifications subject to change without prior notice.
2010 WHEATON Industries Inc.
