COMPONENT ACCESS
French-Door Boom Mount Refrigerator
n
3-3
Accessing the Refrigerator Door Parts
1. Using a Philips screwdriver, remove the hinge cover from the
top hinge.
2. (Le Door Only) Disconnect the water dispenser tubing
located on top of the door hinge. Firmly pull up on the clasp.
Then,pull the tubing out of the ng.
NOTE: The water dispenser tubing remains aached to the
le-hand refrigerator door.
3. (Le Door Only) Disconnect the wiring connectors located on
the top of the door hinge.
NOTE: Do not remove the green ground wire. It should
remain aached to the door hinge.
4. Use a TORX
®
T25 screwdriver to remove the three screws
from the top hinge.
5. Open the door to 90° to the front of the cabinet and li the
door from the boom hinge pin.
6. Place mullion in the door closed posion and remove the
1/4" screw at the center of the mullion.
7. Slide the mullion up to remove from the tabs at the top and
boom hinges.
8. Disconnect the wiring connector for the mullion heater and
remove the mullion.
NOTE: When installing the mullion,ensure the wiring
connector is placed behind the plasc retaining clip.
1. Remove the ice bucket.
2. Depress the plasc tabs on the boom le and right sides of
the lcemaker and slide out.
3. Disconnect the wiring connector and remove the lcemaker.
4. Disconnect the ice maker ll tube (blue) clasp under the le
hinge cap.
5. Use pliers to pull ll tube and heater from top of the ice
maker housing.
NOTE: Aach a string to the clasp end of the ll-tube to aid in
shing through the new ll tube.
1. Remove the ice bucket.
2. Remove the four Philip screws retaining the ice chute plate.
3. Remove the four 1/4" screws from the ice dispenser motor
and li out.
4. Disconnect the wiring connector and remove the ice
dispenser motor.
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
