Whirlpool KRFC704FSS - Refrigerator Compartment Component Access

COMPONENT ACCESS
French-Door Boom Mount Refrigerator
n
3-5
Accessing Refrigerator Compartment Components

1. Li and angle the two tuck shelves, and the full shelf to
remove from the cabinet.
2. Fully extend and li the rear rollers from the track to remove
the crisper drawers and temperature controlled drawer.

1. Release the ten plasc tabs holding the air cover in place, and
remove the air tower cover.
2. Disconnect the wiring connector for the air lter assembly
LED lights.
3. Release the eight plasc tabs on the air lter assembly and
remove.
NOTE: Certain areas of the liner are cut with a laser during
manufacturing. It is normal to see smoke staining on the liner
in these areas.

1. Use a puy knife to release the thirteen plasc tabs holding
the LED Light in place.
2. Slowly remove the light from the liner, disconnecng the
wiring connector.
3. When installing the light, connect the wiring connector rst,
ensuring the LED turns on.
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
Smoke Staining
from
Laser Cutting
