WHYTE Service Manual
Frame Size X Small Medium Large
Head Angle A 66.0° 66.0° 66.0°
Seat Angle B 73.5° 73.5° 73.5°
Top Tube C 575.7mm 599.0mm 624.4mm
BB Height* D 338mm 338mm 338mm
Stand Over E 795mm 803mm 810mm
Wheel Base F 1135.5mm 1159.4mm 1184.8mm
Chain Stay G 440mm 440mm 440mm
Seat Post H 30.9mm 30.9mm 30.9mm
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at front and rear. Please refer to suspension set up for information on how to achieve the correct sag of the
fork and rear damper.
* BB height with Ø686mm tyres fitted (2.5” / 60-559)
2.2: Whyte T-120 Geometry
Frame Size X Small Medium Large
Head Angle A 68.0° 68.0° 68.0°
Seat Angle B 73.0° 73.0° 73.0°
Top Tube C 578.7mm 598.2mm 610.8mm
BB Height* D 341.5mm 336.5mm 334.5mm
Stand Over E 756m 777mm 800mm
Wheel Base F 1093.4mm 1119.3mm 1135.1mm
Chain Stay G 425mm 425mm 425mm
Seat Post H 27.2mm 27.2mm 27.2mm
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at front and rear. Please refer to suspension set up for information on how to achieve the correct sag of the
fork and rear damper.
* BB height with Ø673mm tyres fitted (2.2” / 52-559)
2.1: Whyte 146 Geometry
