Page 7 2010 Edition 1
WHYTE Service Manual
Notes:
Geometry shown here is ‘Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at front and rear. Please refer to suspension set up for information on how to achieve the correct sag of the
fork and rear damper.
* BB height with Ø673mm tyres fitted (2.2” / 52-559)
Frame Size X Extra-Small Small Medium Large
Head Angle A 69.6° 69.6° 69.6° 69.6°
Seat Angle B 71.6° 71.6° 71.6° 71.6°
Top Tube C 571.9mm 583.5mm 596.2mm 610.3mm
BB Height* D 354mm 354mm 354mm 354mm
Stand Over E 728mm 742mm 754mm 781mm
Wheel Base F 1058.4mm 1070.7mm 1083.8mm 1098.8mm
Chain Stay G 420mm 420mm 420mm 420mm
Seat Post H 30.9mm 30.9mm 30.9mm 30.9mm
2.4: Whyte E-120 Geometry (with 130 Fork)
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at front and rear. Please refer to suspension set up for information on how to achieve the correct sag of the
fork and rear damper.
* BB height with Ø673mm tyres fitted (2.2” / 52-559)
Frame Size X Extra-Small Small Medium Large
Head Angle A 68.7° 68.7° 68.7° 68.7°
Seat Angle B 70.6° 70.6° 70.6° 70.6°
Top Tube C 574.8mm 586.5mm 599.3mm 613.3mm
BB Height* D 359.7mm 359.7mm 359.7mm 359.7mm
Stand Over E 734mm 748mm 760mm 787mm
Wheel Base F 1064.5mm 1076.7mm 1090.1mm 1104.8mm
Chain Stay G 420mm 420mm 420mm 420mm
Seat Post H 30.9mm 30.9mm 30.9mm 30.9mm
2.3: Whyte E-120 Geometry (with 120 Fork)
