widos 4001 - Page 38

Kunststoffschweißtechnik
Foundation: 2207, 2208 DIN 16932 German association for welding
Use for:
4000 / 4001 / 4002
1 bar on manometer:
23
N
time to
change- reach full
over welding cool-down time
0,10 (PP) time pressure pressure in
T desired
temperature
time
pipe
pipe
SDR
bead-up
circular
heat-up
max.
time
welding
cool-
diameter
wall
pressure
bead
time
change-
to reach
pressure
down
OD
(s)
[bar]
min.
[s]
over
welding
[bar]
time
[mm]
[mm]
[mm]
time
pressure
[min]
[s] [s]

Table for PP
Additional to the given bead-up force and to the welding force the moving force of the support must be added !
The standard value for heating element temperature is 210° C +/- 10° C.
welding area
in welding area
The
smaller
the pipe wall the
higher
the temperature.
P (N/mm²)
bead-up heat-up
315
7,7 41 33 1,0 185 6 8 33 13
315
9,7 33 41 1,0 213 7 9 41 16
315
12,1 26 51 1,0 246 7 11 51 20
315
17,9 17,6 73 1,0 317 9 16 73 28
315
28,6 11 112 2,0 420 12 24 112 44
355
8,7 41 42 1,0 199 6 8 42 15
355
10,9 33 52 1,0 230 7 10 52 18
355
13,6 26 64 1,0 264 7 12 64 22
355
20,1 17,6 92 1,5 341 9 18 92 32
355
32,2 11 142 2,0 448 13 28 142 48
400
9,8 41 53 1,0 214 7 9 53 16
400
12,3 33 66 1,0 249 7 11 66 20
400
15,3 26 81 1,0 221 7 10 81 17
400
22,7 17,6 117 1,5 367 10 20 117 35
400
36,3 11 181 2,0 480 14 31 181 54
450
11,0 41 66 1,0 231 7 10 66 18
450
13,8 33 83 1,0 267 8 13 83 23
450
17,2 26 102 1,0 308 8 15 102 27
450
25,5 17,6 148 1,5 395 11 22 148 39
450
40,9 11 229 2,5 508 15 35 229 59



Remaining under the cool-down time for up to 50% is allowed under the following conditions:
•
prefabrication under workshop conditions
•
low additional pressure at unclamping
•
no additional pressure during further cooling down
•
load onto the workpieces only after being completely cooled down
•
Join parts with wall thickness
≥15 mm
25.06.2012 Working instructions WIDOS 4000 - 4002 Page 29 / 4 of 59
