widos 4001 - Heating Element; Planer; Hydraulic Aggregate; Basic Unit

Kunststoffschweißtechnik
Description of product Chapter 1
25.06.12 Working instructions WIDOS 4001 Page 8 of 59
1.4.1.2. Heating element
Power: 3,6 kW / 5,4 kW (for conversation kit)
Voltage: 230 V (± 10%) / 400 V (for conversation kit)
Amperage: 16 A (± 10%)
Frequency: 50 Hz
Surface: antisticking coated
Mounted elements: - electronic temperature control
- control lamps
- on/off switch (for conversation kit)
1.4.1.3. Planer
Motor: Monophase universal motor
Power: 1,05 kW / 1,4 kW for conversion kit
Voltage: 230 V (± 10%)
Amperage: 3,8 A / 4,9 A for conversation kit
Frequency: 50 Hz (± 10%)
Gear: Gear ratio: approx. 0,12
Revolutions of planer [1/min] 50 - 70
1.4.1.4. Hydraulic aggregate
Power: 300 Watt
Voltage: 230 V (± 10%)
Amperage: 2,7 A
Frequency: 50 Hz
Phase displacement: approx.18°
Hydraulic oil tank: approx. 1 l
Type of protection IP 54
Electric motor and pump:
Engine revolution: 1380 U/min
max. working pump: approx. 250 bar
Working pressure: adjustable up to 250 bar
1.4.1.5. Basic unit
Dimension l x w x h: 1220 x 1000 x 1355 (mm)
Frame material: Constructin steel
Cylinder-∅: 25 mm
Piston rod-∅: 18 mm
max.force (F=P*A) 236 N (at 100 bar)
5,9 kN (at 250 bar)
Moving speed of the piston: approx. 5,6 cm/s
