Kunststoffschweißtechnik
Spare parts list Chapter 9
Pos. Name Piece Order no.
1 Linear guide with slide 2 L30600TR
2 Pan-head screw M 8x30 DIN 912 16 0912H030
3 Cap for linear guide 16 L30601
4 Rear girder 1 023104
5 Rivet nut M 10 10 N1002
6 Transport grip 2 020123
7 Pan-head screw M 8x55 DIN 912 16 0912H055
8 Frontal girder 1 023102
9 Rivet nut M 10 10 N1002
10 Crossgirder for basic frame 2 024103
11 Protective cap (50x50x4 mm) 4 J0208
12 Basic frame 1 024101
13 Slide 4 L20ELZ
14 Pan-head screw with low head M 6x14 DIN 7984 16 7984F014
15 Linear guide 2 L20700
16 Fitting cap 24 L20501
17 Pan-head screw M 5x16 DIN 912 24 0912E016
18 Stop pin 1 024105
19 Washer M 10 DIN 125 2 0125J
20 Parallel pin M 5x18 DIN 6325 4 6325E018
21 Hydraulic cylinder 1 023115
Seals for cylinder 1 set D023115
22 Pan-head screw M 8x25 DIN 912 3 0912H025
23 Grub screw M 6x10 DIN 913 1 0913F010
24 Shaft (d = 25, l= 275 mm) 1 023120
25 Guide bearing 1 LKH2540
26 Slide, left 1 023105
27 Thread insert M 12 short 2 GEWK-M12
28 Thread insert M 12 5 GEW-M12
29 Pan-head screw M 10x90 DIN 912 2 0912J090
30 Pan-head screw M 10x70 DIN 912 4 0912J070
31 Plate, horizontal movement 1 023108
32 Guide rod 2 023107
33 Pan-head screw M 10x40 DIN 912 2 0912J040
34 Thread insert M 10 4 GEW-M10
35 Counter nut M 10 DIN 985 2 0985J
36 Washer M 10 DIN 125 2 0125J
37 Holder for hydraulic box 1 024118
38 Flat-head screw M6x20 DIN 7991 2 7991F020
39 Flat-head screw M6x16 DIN 7991 2 7991F016
40 Clamping lever (threaded length 30 mm) 2 BM10030
41 Straight pin 8x120 DIN 6325 2 6325H120
42 Washer M 8 DIN 125 2 0125H
43 Angular screw coupling 2 VSWV8LL
44 Washer spring A 35,5x18,3x2 DIN 2093 2 2093R020
45 Distance tube 1 023116
25.06.2012 Working instructions WIDOS 4001 Page 39 / 1 of 59
