Spare parts list Chapter 9
Pos. Piece Order no.
1 Center pin 2 020117
2 Supporting angle 2 023712
3 Pipe support 1 Set 0206...*
4 Pipe support 2 023711
5 Clamping lever M 12/30° 2 BM1230
6 Insert nut 2 023713
7 Guide rail 2 023724
8 Pan-head screw M 10x20 DIN 7984 8 7984J020
9 Straight pin 8x20 DIN 6325 4 6325H020
10 Clamping tool, left DO 335 1 S02335L
11 Clamping tool, right DO 335 1 S02335R
12 Thread spindle 2 091108
13 Nut 2 091109
14 Thrust washer 2 023708
15 Lock washer size 7 DIN 6799 2 6799G
16 Rivet for spindle 2 S0205
17 Hexagon screw M 12x35 DIN 933 6 0933L035
18 Thrust washer 6 023707
19 Rivet for joint 2 S0426
20 Knurled screw 1 S0318
21 Support for bow 1 020721
22 Knurled screw 1 S0222
23 Reduction insert, Ø90 - 280 1 Set 0208...*
-- Reduction insert wide, Ø90 - 280 1 Set 0218...*
-- Reduction insert super wide, Ø90 - 280 1 Set 0228...*
24 Pan-head screw for reduction inserts Ø90-280 4 0912F30X
-- Flat-head screw for reduction inserts Ø315 4 7991F20X
-- Allan key SW 27 1 ZRS27
* When ordering state dimension !
25.06.2012 Working instruction WIDOS 4001 Page 41 of 59
