Kunststoffschweißtechnik
Spare parts list Chapter 9
WIDOS 4001
Pos. Name Piece Order no.
1 Heating element H 4002, 230 V 1 H4002E
Heating plate new 1 HP4002E
Heating plate in exchange 1 HPT4002E
2 Stud bolt M 12 1 HGEW-M12
3 Grip for heating element 1 H0205
4 Handlebar 1 H0206
5 Sensor PT 1000 1 H09082
6 Holder for sensor 1 023536
7 French head screw M 4x 6 DIN 7985 2 7985D006
8 Toothead lock washer M 4 DIN 6797 1 679D
9 Guard plate for heating element 1 023535
10 Oval-head screw M 3x5 DIN 7985 6 7985C005
11 Cover plate 1 H2116
12 Antikink union joint PG11 1 EV0011
13 Connection cable with plug 1 EK3220
14 Cap for control 1 H2115
15 Housing with cap for control 1 H2114
16 Flat-head screw M 6x12 DIN 7991 8 7991F012
17 Pan-head screw M 5x25 DIN 912 2 0912E025
18 Washer M 5 DIN 125 2 0125E
19 Spring washer M 5 DIN 127 2 0127E
20 PTFE-distance washer 2 H2110
21 Blind rivet 4 7337D010
22 Control lamp yellow 1 H2106
23 Button for thermo regulator with cover cap 1 H2109
24 Frame for heating element 1 on request
25 PTFE-distance washer 1 H2103
26 Control lamp green 1 H2105
27 Screen 1 on request
28 Screen with temperature scale 180-280 1 on request
29 Electronic control GZ 4 without sensor 1 H0928220
30 Triac 1 H09083
31 Sensor PT 1000 1 H09082
32 Teminal lustre, triple 1 EA1001
33 Pan-head screw M 3x12 DIN 912 2 0912C012
34 Knee for terminal lustre 1 H2112
35 Flat-head screw M 4x10 DIN 7991 1 7991D010
25.06.2012 Working instructions WIDOS 4001 Page 46 of 59
