Kunststoffschweißtechnik
Spare parts list Chapter 9
WIDOS 4001
Heating element holder
Pos. Name Piece Order no.
1 Retaining plate whith thread 1 024501
2 Roller 4 023503
3 O - ring 4 D18x4
4 Pan-head screw M10x55 DIN 912 4 0912J055
5 Washer M10 DIN 125 6 0125J
6 Pan-head screw M10x70 DIN 912 1 0912J070
7 Washer M10 DIN 9021 1 9021J
8 Hexagon nut M 10 DIN 934 1 0934J
9 Pan-head screw M5x20 DIN 912 1 0912E020
10 Hexagon nut M5 DIN 934 1 0934E
11 Mounting plate 1 024405
12 Pan-head screw M6x20 DIN 912 8 0912F020
13 Bolt for retaining plate 1 024404
14 Pan-head screw M10x25 DIN 912 1 0912J025
15 Washer M10 DIN 9021 1 9021J
16 Retaining plate whith hole 1 024502
25.06.2012
Working instructions WIDOS 4001 Page 48 of 59
