Kunststoffschweißtechnik
Spare parts list Chapter 9
WIDOS 4001
Conversion kit for clamping tools
Pos. Name Piece Order no.
1 Spindle nut 2 071109
2 Thrust washer 2 023708
3 Thread spindle 2 071108
4 Lock washer size 8 DIN 6799 2 6799H
5 Rivet for spindle 2 S0425
6 Set clamping tools OD 450 1 S04450
7 Rivet for joint 2 S0426
8 Pipe support conversion kit 2 040711
9 Pipe support OD 400 - 315 2 0406...*
10 Hexagon head screw M 12x35 DIN 933 6 0933L035
11 Thrust washer 6 160110
-- Allan key SW 27 1 ZRS27
-- Screw for reduction inserts 4 7984J30X
-- Reduction inserts 2 0708...*
* When ordering state dimension !
25.06.2012 Working instructions WIDOS 4001 Page 50 of 59
