widos 4001 - Page 62

Kunststoffschweißtechnik
Spare parts list Chapter 9
WIDOS 4001
Conversion kit for planer
Pos. Name Piece Order no.
1 Ball button C 40 DIN 319 1 0319C40
2 Handle bar 1 040407
3 Hexagon nut M 16 DIN 934 1 0934P
4 Claw 1 023410
5 Bolt 1 023408
6 Guide bolt 1 023407
7 Stud bolt 1 023409
8 Spring 1 023411
9 Planer disc, right 1 043402
10 Fastener for planer 1 043401
11 Ball bearing 2 L6003Z
12 Hexagon nut M 16x1,5 DIN 934 1 0934Y
13 Disc M 16 DIN 125 4 0125P
14 Bolt 1 210410
15 Driving motor 1040 W, 230 V 1 AMBF23
16 Connection cable 1 EK3220
17 Collector carbon 1 set EKMBF23
18 Switch for driving motor 1 on request
19 Planer disc, left 1 043403
20 Cover 1 043404
21 Pan-head screw M 4x16 DIN 912 4 0912D016
22 Blade 4 MES085
23 Spacer 4 MU085
24 Flat-head screw M 3x8 DIN 965 6 0965C008
25 Pan-head screw M 10x40 DIN 912 4 0912J040
26 Blade 2 MES170
27 Spacer 2 MU170
28 Flat-head screw M 3x8 DIN 965 18 0965C008
29 Ball bearing 1 L61834
30 Chain wheel, small (11 teeth) 1 K38011
31 Chain wheel disc 3/8" (95 teeth) 1 023406
32 Chain 3/8" (151 links) 1 K38151
33 Chain joint 3/8" 1 KSCH38
34 Flat-head screw M 8x20 DIN 7991 4 7991H020
35 Plate 2 043429
36 Pan-head screw M 8x35 DIN 912 2 0912H035
25.06.2012 Working instructions WIDOS 4001 Page 52 of 59
