Kunststoffschweißtechnik
Spare parts list Chapter 9
WIDOS 4001
Conversion kit for heating element
Pos. Name Piece Order no.
1 Heating element holder 1 HU4002E
Heating plate new 1 HPU4002E
Heating plate in exchange 1 HPTU4002E
2 Lifting eye screw M 10 DIN 580 1 0580J
3 Heat sink 1 on request
4 Frame 1 071558
5 Pan-head screw M 8 x 30 DIN 912 2 0912H030
6 Insulating piece 1 071556
7 Cover for heating element holder 1 3555478
8 Drive-in nut 4 05460098
9 Pan-hed screw M 6 x 16 DIN 7984 8 7984F016
10 Spring loxk washer M 6 DIN 127B 8 127F
11 Heating element holder 1 071558
12 Temperature probe PT 1000 1 H09082
13 Insertion nut 1 HGEW-M12
14 Hexagon nut M 12 DIN 439B 1 0439L
15 Guard plate 1 355549
16 Handlebar 1 355544
17 Ball button Ø 40 1 on request
18 Controller G4 with triac 1 H0908230D1
19 Window, tinted 1 H09071
20 Screw connection HKL 1 EVH21201615
21 Rubber cable 5 x 1,5², 3,2 m 1 EL02515
22 Cekon - plug 16A 1 EST0116
23 Distance piece 4 081554
24 Tapped bushing 4 081553
25 Pan-head screw M 6x45 DIN 912 4 0912F045
26 Upper and lower part of housing 1 081551
27 Flat-head screw M 3x8 DIN 7991 2 7991C008
28 PTFE - joining piece 1 211505
25.06.2012 Working instructions WIDOS 4001 Page 54 of 59
