Kunststoffschweißtechnik
Spare parts list Chapter 9
Pos. Name Piece Order no.
1 Hydraulic box 1 024227
2 French head screw M 3,5x13 DIN 7983 12 7983C013
3 Disc of roses M 3,5 12 ROSM 3.5
4 Cover for hydraulic box 1 024226
5 Pressure gauge (0-250 bar) 1 020204
6 Bellows 1 101035
7 Hook for removable hydraulic unit 2 024119
8 Counter plate for hook 2 0241191
9 Flat-head screw M 6x16 DIN 7991 4 7991F016
10 Fastener for stop-watch 1 023917
11 Flat-head screw M 4x10 DIN 965 3 0965D010
12 Cylinder knob 1 on request
13 Screw coupling for mini measuring tube 1 VSK02
14 Screw connection for WIDOS 4001 2 1010242
15 O-ring 18x1,5 2 D18x15
16 Mini measuring tube 1 V0400140
17 Hydraulic unit 1 023203
18 Accumulator (10 bar) 1 103206
19 Pipe duct size 22 1 EKT22
20 Coupling plug, flat packing 1 VST14
21 Coupling box, flat packing 1 VMU14
22 Bow type handle 2 BG565201
23 Pan-head screw M 6x14 DIN 7984 4 7984F014
24 Washer M 6 DIN 9021 4 9021F
25 Sealing nipple 2 VB306
26 Bow shaped nipple 2 VB386
27 Compressed bushing 4 VP256
28 Hydraulic hose 1,7 m VSCHL61
29 Hydraulic hose 1,9 m VSCHL61
30 Protective hose (28x2 mm) 1,2 m EA08011
31 HKL-screw connection Pg 13/11 1 EVH1311
32 Counter nut (brass) for Pg 13.5 1 EV0213
33 Cable H07RN-F (3x1,5 mm²) 3,0 m EL02315
34 Plug with earthing contact (230 V) 1 EST0702
-- Stop-watch 1 TMZ1000
25.06.2012 Working instructions WIDOS 4001 Page 56 of 59
