Ku nst sto ffschwei ß tec hni k
Foundation: 2207, 2208 DIN 16932 German association for welding
The value for heating element temperature is between 200° C - 220° C.
The standard value for heating element temperature is 220° C.
Increase the change-over time and the welding pressure time at PE 100 as fast as possible !
time to
change- reach full
over welding cool-down time
0,15 (PE) time pressure
pressure in
T
desired
temperature
time
in welding area
Table for PE
bead-up heat-up
Additional to the given bead-up force and to the welding force the moving force of the support must be added !
welding area
P (N/mm²)
4,4 41,0 7 0,5 44 5 5 7 6
5,5 33,0 8 1,0 55 5 5 8 8
6,9 26,0 10 1,0 69 6 6 10 10
8,6 21,0 12 1,5 86 7 7 12 12
10,2 17,6 14 1,5 102 7 7 14 14
10,7 17,0 15 1,5 107 7 7 15 14
13,3 13,6 18 2,0 133 8 9 18 17
16,4 11,0 22 2,0 164 9 10 22 21
20,1 9,0 26 2,5 201 10 11 26 25
24,6 7,4 31 2,5 246 12 13 31 30
4,9 41,0 8 1,0 49 5 5 8 7
6,2 33,0 10 1,0 62 6 6 10 9
7,7 26,0 12 1,5 77 6 6 12 11
9,6 21,0 15 1,5 96 7 7 15 13
11,4 17,6 18 1,5 114 8 8 18 15
11,9 17,0 18 1,5 119 8 8 18 16
14,7 13,6 22 2,0 147 9 9 22 19
18,2 11,0 27 2,0 182 10 11 27 23
22,4 9,0 32 2,5 224 11 12 32 28
27,4 7,4 38 3,0 274 13 15 38 34
5,5 41,0 10 1,0 55 5 5 10 8
6,9 33,0 13 1,0 69 6 6 13 10
8,6 26,0 15 1,5 86 7 7 15 12
10,8 21,0 19 1,5 108 8 8 19 15
12,8 17,6 22 2,0 128 8 8 22 17
13,4 17,0 23 2,0 134 8 9 23 18
16,6 13,6 28 2,0 166 9 10 28 21
20,5 11,0 34 2,5 205 10 12 34 26
25,2 9,0 41 2,5 252 12 14 41 31
30,8 7,4 48 3,0 308 14 16 48 38
02.11.2011 Working instructions WIDOS 4900 Page 25 / 3 of 46
