Description of product Chapter 1
02.11.11 Working instructions WIDOS 4900 Page 7 of 46
1.3. Safety measures
In case of wrong use, wrong operation or wrong maintenance the machine itself or products
being in the surrounding can be damaged or destroyed.
Persons being in the endangered area may be injured.
Therefore these working instructions have to be thouroughly read and the corresponding safety
advices must be necessary adhered to.
1.4. Conformity
The machine corresponds in its construction to the valid recommendations of the European
Community as well as to the European standard specifications.
The development, manufacturing and mounting of the machine were made very carefully.
1.5. Designation of product
The product is designated by two signs at the frame.
The type-labels are fixed on the control unit and on the basic machine.
They contain the type of the machine, the serial number, and the year of construction.
1.5.1 Technical Data
1.5.1.1 WIDOS 4900 General data
Material: PP, PE 80, PVDF, PE 100
Pipe diameter range: outside-∅ = 90 – 315 mm
Transport box (l x w x h) / weight:
Partition boxes for reduction inserts:
4- partition:
7- partition:
9- partition:
approx. 1230 x 980 x 670 mm / approx. 67 kg
appr. 680 x 410 x 310 weight: appr. 10 kg
appr. 1160 x 410 x 310 weight: appr. 16 kg
appr. 1470 x 410 x 310 weight: appr. 21 kg
Total weight (without packing): approx. 130 kg
Protection: 16 A
Wire cross section: 1,5 mm²
Emissions - Noises exceeding 80 dB (A) may occur; during
planing it is obligatory to wear ear protection!
- when using the named pipe materials and when
welding below 260° C no toxicant damp arises.
