Description of product Chapter 1
02.11.11 Working instructions WIDOS 4900 Page 9 of 46
1.5.1.4 Hydraulic aggregate
Power: 0,3 kW
Voltage: 230 V (± 10 %)
Current: 2,7 A
Frequency: 50 Hz
Hydraulic oil tank: approx. 1 l
Electromotor and pump:
RPM: 1380 (revs/min.)
max. pressure of pump: approx. 120 bar
Working pressure: 100 bar
Volume velocity: 1,9 l/min
Weight : approx. 23 kg
1.5.1.5 Basic frame
Dimensions (l x w x h): 800 x 460 x 500 mm
Reduction insert : Dimensions can be selected
Material frame: Machine steel
Material reduction inserts: Aluminium
Weight: approx. 60 kg
Cylinder-∅: 40 mm
Piston rod-∅: 35 mm
Length of stroke of cylinder: 175 mm
max. force: (F=P*A) 5900 N (at 100 bar)
Velocity of piston rod: 5,4 cm/s
Stock numbers for component parts see spare parts list
1.6. Equipment and accessories:
The following accessories are part of the first delivery:
1 Tool bag for 10 parts
1 Socket wrench size 27
1 each Allan key size 3; 6; 7; 8
1 each Allan key with T-grip size 5; 7
optional Reduction inserts, roller brackets for the pipes
1 Torx-screw driverT10
