Ku nst sto ffschwei ß tec hni k
Spare parts list Chapter 10
Basic machine WIDOS 4900
Pos. Name Piece Art.-No.
1 Outer clamp, fixed 1 216101
2 Inner clamp, fixed 1 216102
3 Inner clamp, movable 1 216103
4 Outer clamp, movable 1 216104
5 Upper clamp 4 214105
6 Thread insert M 6 8 GEW-M6
7 Nut 8 091109
8 Thrust washer M 14 DIN 6340 8 6340N
9 Threaded spindle 8 091108
10 Rivet 8 091111
11 Lock washer size 7 DIN 6799 8 6799G
12 Flat head screw M 12x20 DIN 7991 2 7991L020
13 Lock washer size 7 DIN 6799 8 6799G
14 Hydraulic cylinder 2 216106
Gasket set for cylinder 2 set D216106
15 Retainer ring 6x9,3x1 4 D6x9,3
16 Cylinder head screw M 6x10 DIN 912 4 0912F010
17 Hydraulic hose (40 mm) 2 216113
18 Filter 2 V092114
19 Hydraulic hose (320 mm) 2 216112
20 Pull shaft 2 216107
21 Counter nut M 8 DIN 985 2 0985H
22 Washer M 8 DIN 125 2 0125H
23 Hose bunch 1 VSCHL4900
24 Spiral pin 4x40 DIN 7343 4 7343D040
25 End bolt 2 091117
26 Thrust washer 2 216133
27 Holder for filter 2 092120
28 Washer M6 DIN 9021 2 9021F
29 Hexagon-head screw M 6x16 DIN 933 2 0933F016
30 Basic frame 1 216118
Floor plate for basic frame 1 2161182
31 Shaft 3 091131
32 Flat head screw M 12x30 DIN 7991 6 7991L030
33 Tear off bar for heating element 1 216503
34 Hexagon-head screw M 8x12 DIN 933 2 0933H012
35 Washer M 8 DIN 125 2 6340H
36 Support 1 216141
37 Protective cap 40 x 30 6 J0203
38 Pan-head screw M 8x25 DIN 912 3 0912H025
39 Protective cap, round SL 20x1-2 3 J0215
40 Pan-head screw M 10x20 DIN 912 2 0912J020
02.11.2011 Working instructions WIDOS 4900 Page 36 / 1 of 46
