Pos. Name Piece Art.-No.
1 Limit switch, complete 1 ES0102
2 Knife 2 MES170
3 Flat-head screw M 3x8 with Torx-drive 12 0965C008TX
4 Disc planer, righthand 1 216402
5 Ball bearing 2 L6001Z
6 Chain tensioner screw 1 0914101
7 Hexagon nut M 12 DIN 934 1 0934L
8 Washer M 12 DIN 125 3 0125L
9 Washer M 12 DIN 134 1 0134L
10 Switch cover for planer 1 091420
11 Flat-head screw M 5x12 DIN 7991 2 7991E012
12 Fastener for planer 1 216401
13 Bow grip 1 BG56520
14 Pan-head screw M 6x16 DIN 912 2 0912F016
15 Cover tube 1 216405
16 Grub screw M 4x8 DIN 913 1 0913D008
17 Pan-head screw M 8x30 DIN 912 2 0912H030
18 Locking bolt complete 1 091422
19 Pan-head screw M 8x30 DIN 912 2 0912H030
20 End sleeve for strands with ring M 4 1 EA05425
21 Tooth lock washer M 4 DIN 6797 1 6797D
22 Lens head screw M 4x8 DIN 7985 1 7985D008
23 Connecting cable with plug 1 EK3220
24 Driving motor 1050 W, 230V 1 AMBF16
25 Motor switch 1 ESMBF16
26 Collector carbon 1 set EKMBF16
27 Disc planer, lefthand 1 216403
28 Chain wheel, small (11 teeth) 1 K38011
29 Chain 3/8" (103 links) 1 K38103
30 Chain joint 1 KSCH38
31 Ball bearing 1 L6013
32 Flat-head screw M 6x12 DIN 7991 4 7991F012
33 Chain wheel, large 3/8" x 7/32" 1 091406
34 Cover 1 216404
35 Pan-head screw M 4x16 DIN 912 2 0912D016
-- Torx-screw driver T10 1 ZT10
02.11.2011 Working instructions WIDOS 4900 Page 38 of 46
